Firewall/VPN Performance	NSsp13700
Firewall inspection throughput¹	60 Gbps
Threat prevention throughput²	45.5 Gbps
Application inspection throughput²	57 Gbps
IPS throughput²	48 Gbps
TLS/SSL inspection and decryption throughput (DPI SSL)²	16.5 Gbps
VPN throughputᵌ	29 Gbps
Connections per second	280.000
Maximum connections (SPI)	25.000.000
Maximum connections (DPI)	22.000.000
Maximum connections (DPI SSL)	2.000.000
VPN
Site-to-Site VPN Tunnels	12.000
IPSec VPN clients (Maximum)	2.000 (6.000)
SSL VPN licenses (Maximum)	2 (3.000)
¹Testing Methodologies: Maximum performance based on RFC 2544 (for firewall). Actual performance may vary depending on network conditions and activated services.
²Threat Prevention/GatewayAV/Anti-Spyware/IPS throughput measured using industry standard Keysight HTTP performance test tools. Testing done with multiple flows through multiple port pairs. Threat Prevention throughput measured with Gateway AV, Anti-Spyware, IPS and Application Control enabled
ᵌVPN throughput measured with UDP traffic using 1418 byte packet size AESGMAC16-256 Encryption adhering to RFC 2544. All specifications, features and availability are subject to change
